New Product Series
Product Introduction
SC-9288 is a one-component silicone resin hybrid coating. It appears as a colorless and transparent liquid, and forms a transparent, dense and hard resin coating after curing, which features high strength and scratch resistance. It contains ultra-low solvents, is almost odorless, and is more green and environmentally friendly. With a solid content of over 85%, the single coating can reach a dry film thickness of 50-200 microns.
Product Applications
The SC-9288 product is suitable as a protective coating for both rigid and flexible circuit boards, especially in application scenarios that require toughness and wear resistance.
Product Data
| ltem | Test Standard | Typical Data |
|---|---|---|
| Appearance | Visual inspection | Colorless transparent liquid |
| Solid Content,% | GB/T 1725-2007 | ≥ 85 |
| Viscosity,25℃,CPs | GB/T 10247-2008 | 700~1000 |
| Hardness | GB/T 531.1-2008 | 30~40HD |
| Special Gravity,25℃,g/cm³ | GB/T 13354-1992 | 1.02~1.05 |
| Volume Resistivity,Ω.cm | GB/31838.2-2019 | 1015 |
| Adhesion | GB/T 9286-2021 | Level 0 |
| HighTemp And High Humidily Exposure | IEC60068-2-2:2007(1000h) | Pass |
| Thermal Shock | IPC-TM-650 2.6.7.1A:2000 | Pass |
| Salt Water Spray Test | GJB 150.11A-2009 | Pass |
| Antibacterial Test | GJB 150.10A-2009 | Level 0 |
